Audio-Technica BP40 Large Diaphragm Dynamic Broadcast Microphone

Share

The Audio-Technica BP40 broadcast vocal microphone offers a rich, natural, condenser-like sound from a large-diaphragm dynamic design. The large diaphragm features patented floating-edge construction that maximizes diaphragm surface area and optimizes overall diaphragm performance, while the humbucking voice coil prevents electromagnetic interference (EMI).

With rugged construction and stylish, waveform-inspired design, the BP40 delivers clear and articulate reproduction. Optimized capsule placement helps maintain a commanding vocal presence even at a distance, while the multistage windscreen provides superior internal pop filtering. Microphone also includes a switchable 100 Hz high-pass filter to provide even more pop protection.

Audio-Technica BP40 - Features:

• Rich, natural, condenser-like sound
• Large diameter diaphragm with patented floating-edge construction for optimal diaphragm performance
• Humbucking coil prevents electromagnetic interference (EMI)
• Hypercardioid polar pattern improves isolation
• Switchable 100 Hz high-pass filter
• Superior off-axis rejection for maximum gain before feedback
• Optimized capsule placement for commanding vocal presence even at a distance
• Multistage windscreen provides superior internal pop filtering
• Rugged, all-metal construction for dependable use in professional broadcast environments

• Element: Dynamic
• Polar Pattern: Hypercardioid
• Frequency Response: 50 - 16,000 Hz
• Low Frequency Roll-Off: 100 Hz, 6 dB/octave
• Impedance: 450 Ω
• Switch: Flat, roll-off
• Output Connector: Integral 3-pin XLRM-type
• Accessories Included:
  • AT8483 mounting clamp for 5/8"-27 threaded stands
  • 5/8"-27 to 3/8"-16 threaded adapter
  • Soft protective pouch
• Dimensions (L x Diameter): 164 mm (6.45") x 56 mm (2.2")
• Weight: 632 g | 22.3 oz
