Sound Devices MixPre-3 II 3-Preamp, 5-Track (3+2ch Mix), 32-Bit Float Audio Recorder with USB Audio Interface

Share

The MixPre-3 II from Sound Devices is designed for those who record field audio, sound effects, podcasts, voice-overs, music, audio for film, or are just starting their audio journey. With three crystal-clear, ultra low-noise Kashmir preamps, the MixPre-3 II can record multiple actors, multiple podcasters, or audio for small productions with superior quality—all the way up to a 32-bit float bit depth and a 192 kHz sample rate. This second generation of MixPre Series has been redesigned for increased performance and an astounding 142 dB of dynamic range.

The MixPre-3 II is highly customizable to your needs. Record internally to a compatible SD card on set or stream your podcast over USB to your computer at home. Power with your computer, wall power, or record in the middle of nowhere with AA or Sony L-mount batteries. Adjust limiters, bit depth, sample rates, gain, pan, low-cut, phase inversion and phantom power to your liking. Trigger your camera with the internal timecode generator, or feed timecode in via HDMI or Aux In. The choice is yours! Professionals love the flexibility of the MixPre Series. Don't need all these options? Basic mode has you covered.

The MixPre-3 II is rugged, lightweight, and small, so you can throw it in a bag or mount it to a tripod or camera – or get situated on set with the Sound Devices Wingman App and one their four supported USB control surfaces. With the superior sound and build quality, the MixPre-3 II can capture audio for any application.

Sound Devices MixPre-3 II - Features:

• Bit depth up to 32-bit float for increased dynamic range
• 32-bit float USB audio ASIO driver (download required)
• Record up to 192 kHz
• Faster, more advanced hardware
• Internal LTC Timecode Generation and Output
• Adjustable limiters
• Auto-copy to USB drive
• Pre-roll buffer increased to 10 seconds
• Three ultra-low-noise Kashmir microphone preamps with adjustable limiters capture high quality audio in the field, on set, or with a computer
• Create a mix using the built-in 3 x 2 portable mixer
• Record up to 5 tracks to an SD card and backup to a USB thumb drive
• 5-in, 2-out USB audio interface streams to your computer via USB-C
• Choose bit depths from 16 to 32-bit float, and sampling rates from 44.1 kHz to 192 kHz
• Internal LTC timecode generator. Timecode In/Out via Aux In/Stereo Out.
• Timecode and record triggering via HDMI
• USB-A for control surfaces, keyboards, and auto-copy to USB drive
• In-unit ISO mixing, gain, pan, low-cut, phase inversion, and phantom power
• Sunlight-readable color touch screen and LED metering
• Lightweight, durable, and small: perfect for bag use, mobile recording, or a home studio
• Powerful 300 mW+300 mW headphone amp allows clear and accurate reference of audio
• Includes an MX-4AA Battery Sled (batteries not included), MX-PSU AC Power Supply, and USB-C to USB-C cable
• Customize with plugins from the Sound Devices Plugin Store

• Audio Inputs:
  • Frequency Response: 10 Hz to 80 kHz +/- 0.5 dB re 1 kHz @ 192 kHz sample rate
  • THD + Noise: 0.005% max (@1 kHz, 22-22 kHz BW, gain = 20 dB, -10 dBu in)
  • ADC: 32 bit precision; 142 dB dynamic range min (A weighted, gain = 10 dB, fader = 0 dB)
  • Equivalent Input Noise: -130 dBV (-128 dBu) max (A-weighted, gain = 76 dB, 150 ohm source impedance)
  • Inputs:
    • Mic: XLR active-balanced; 4k input
    • Line: XLR active-balanced; 4k input
    • Aux/Mic in: 3.5 mm TRS, 2-channel unbalanced; 100k input
    • USB Audio: 2 channels
    • All inputs fully RF-filtered and overload protected
  • Gain:
    • Mic input: +6 dB to +76 dB
    • Line input: -20 dB to +30 dB
    • Fader: -inf to +20 dB
    • Headphone: -inf to +20 dB
    • Total, Mic-to-recording (max): +96 dB
    • Aux In (Mic): Gain = +10 dB to +40 dB
    • Aux In (Line): Gain = -10 dB to +20 dB
    • Total Aux Gain including Fader (Mic-to-recording): +60 dB
  • Maximum Input Level:
    • Mic XLR: +14 dBu (limiters on or off)
    • Line XLR/1/4-inch: +28 dBu (limiters on or off)
    • Aux In (Mic): -10 dBu
    • Aux In (Line): +10 dBu
  • Low Cut Filters: 40 Hz to 160 Hz (adjustable), 18 dB/oct. First stage analog, subsequent stages digital.
  • Microphone Powering:
    • Mic XLRs: 48 V via 6.8k resistors, 10 mA each
    • Mic 3.5 mm: 3 V @ 3k source
  • Limiters: Limiter at all gain stages, range > 40dB. First stage analog, subsequent stages digital. Adjustable Threshold, Ratio, and Release.
• Audio Outputs:
  • DAC feeding Stereo Out, Headphone Out: 32 bit precision; 115 dB dynamic range (A-weighted)
  • L/R Out: 3.5 mm TRS stereo unbalanced, 500 ohm output impedance, +7.8 dBu max output level
  • Headphones Out: 3.5 mm TRS stereo unbalanced, 300 mW + 300 mW, for use with any impedance headphones
• USB:
  • USB | Audio Interface (USB-C): 6-in/2-out (from computer); 44.1 kHz/48 kHz/96 kHz; 16/24/32-bit integer, 32-bit float; Class-compliant USB 2.0 high speed driver
  • Keyboard (USB-A): Text entry and control
  • Thumbdrive (USB-A): Manual or auto-copy to drive
  • Midi Control Surface (USB-A)
• Recording:
  • Maximum Record Tracks: 5 Tracks: Stereo mix + 3 ISOs
  • Sampling Frequency:
    • 44.1 kHz
    • 47.952 kHz
    • 48 kHz
    • 48.048 kHz
    • 96 kHz
    • 192 kHz
  • Bit Depth:
    • 16
    • 24
    • 32 Float
  • Recording Storage:
    • Type: SD, SDXC, SDHC Card, & USB thumbdrive (copy only)
    • Max Storage Size: 512 GB (SDXC)
    • Card format: exFAT
  • File Type: Polyphonic WAV
• Timecode:
  • Modes:
    • Free Run
    • Time of Day (file stamped w/current ToD)
    • Rec Run
    • Ext LTC (file stamped w/incoming LTC on 3.5mm Aux In)
    • Camera TC (file stamped w/incoming TC from cameras that output TC)
  • Frame Rates:
    • Auto-detects (fps): 23.98 (same as 23.976)
    • 24
    • 25
    • 29.97DF
    • 29.97ND
    • 30
    • 30DF
  • 3.5 mm Aux In:
    • Timecode Input
    • Timecode: 20k ohm impedance, 0.3 V - 3.0 V p-p (–17 dBu - +3 dBu)
  • 3.5 mm Stereo Out:
    • Timecode Output
    • Timecode: 1k ohm impedance, 3.0V p-p (+12 dBu)
  • HDMI: TC Reader via HDMI
• Remote Control:
  • Bluetooth LE: Wireless control using Wingman app
  • HDMI (micro): Auto-record start/stop trigger from cameras that output record flag over HDMI
  • Timecode: Auto-record start/stop trigger via Aux In timecode
• Touch Screen: 320x256; 1.6-inch, color, sunlight-viewable IPS LCD
• Power:
  • AA Batteries: 4x AA sled (included); 8x AA sled (optional accessory). NiMH recommended
  • L-Mount: Optional sled for 2x (hot-swappable) Li-ion batteries
  • From computer: Bus-powered via USB-C port
  • AC Adapter: MX-PSU (included) Power supply wall adapter w/ USB-C connector; 15 W; has 4 adapter plugs for US, UK, AU & Europe
• Environmental:
  • Operating: -4° to 140° F | -20° to 60° C, 0 to 90% relative humidity; (non-condensing)
  • Storage: -40° to 185° F | -40° to 85° C
• Dimensions (H x W x D): 1.40 x 5.68 x 4.35 in | 36 x 144 x 110 mm
• Weight: 16.8 oz | 0.48 kg (unpackaged, without batteries)
